HH1 | The HH Mechanical Smokehouse Controller
HH1 is a modern, easy-to-use and reliable controller designed specifically for the food industry. It is capable of being retrofitted to work with all brands of systems.
The HH1 controller provides a more reliable and energy efficient process, with 99 fully customizable program options, multiple control functions and live data tracking.
Areas of Application
Smoking, Cooking, Baking, Maturing, Intensive Cooling, Climate and Climate Smoking
The Controller Explained in 4 Steps
Navigation
- 10" touchscreen display with intuitive user interface
- 4 haptic buttons for main function control
Program
- Program setup directly from the touchscreen
- 99 program options with up to 99 process steps in each program
- 50 individually adjustable process steps (cooking, drying, smoking, etc.)
Running program
- Mid-program adjustable setpoints
- View change values including time, temperature, humidity and core temperature in real-time
- Direct feedback on progress and error handling
Options
- Adjustable basic settings for all users
- Advanced settings - single relay test, sensor calibration, analog outputs, error monitoring, language, etc.
Specifications
